ARICOL MICROWAVE SENSOR DEVICE
MICROWAVE SENSOR DEVICE
Features and Benefits:
- Advanced Microwave Detection: 5.8GHz radar technology provides 360° coverage with an adjustable 1-8m detection range, penetrating walls and glass.
- Adjustable Settings: Customizable ambient light and time delay settings for tailored lighting control.
- Energy Efficient: Low power consumption of approximately 0.9W reduces electricity costs.
- High Load Capacity: ARS700C supports up to 2000W (incandescent) and 1000W (energy-saving), while ARS700CA handles 800W and 300W respectively.
- Wide Installation Range: Suitable for mounting heights from 2-6m, accommodating various ceiling heights.
- Safe Operation: Low transmission power (<0.2mW) ensures minimal electromagnetic interference.
- Versatile Application: Ideal for lighting control in homes, offices, warehouses, and corridors.
- Motion Sensitivity: Detects movement at speeds of 0.6-1.5m/s for consistent performance.
- Durable Design: Built to operate reliably in diverse environments with minimal maintenance.
Description
The Aricol Microwave Sensor Device series is a professional-grade solution engineered to deliver advanced and energy-efficient motion detection for automated lighting control, making it an ideal choice for residential, office, warehouse, and commercial environments. This series includes two models—ARS700C and ARS700CA—both utilizing cutting-edge 5.8GHz CW radar technology within the ISM band to detect motion within a 360° range and an adjustable distance of 1-8 meters. These sensors feature customizable settings for ambient light (3-2000 lux) and time delay (10 seconds to 12 minutes), allowing tailored performance to suit diverse needs. The ARS700C supports a higher rated load of up to 2000W for incandescent lamps and 1000W for energy-saving lamps, while the ARS700CA is designed for lighter loads with a maximum of 800W and 300W respectively, catering to different installation requirements. With low power consumption and a wide installation height range of 2-6 meters, these sensors ensure reliable operation in various settings, making them perfect for electricians, facility managers, and homeowners seeking a smart and efficient lighting solution.
Specifications:
- ARS700C (Aricol Microwave Sensor 700C):
- Type: Microwave Motion Sensor
- Power Source: 220-240V/AC
- Power Frequency: 50/60Hz
- Ambient Light: 3-2000 lux (adjustable)
- Time Delay: Min. 10sec±3sec, Max. 12min±1min
- Rated Load: Max. 2000W (incandescent lamp), 1000W (energy saving lamp)
- Detection Range: 360°
- Detection Distance: 1-8m (radius), adjustable
- HF System: 5.8GHz CW radar, ISM band
- Transmission Power: <0.2mW
- Installation Height: 2-6m
- Power Consumption: Approx. 0.9W
- Detection Moving Speed: 0.6-1.5m/s
- ARS700CA (Aricol Microwave Sensor 700CA):
- Type: Microwave Motion Sensor
- Power Source: 220-240V/AC
- Power Frequency: 50/60Hz
- Ambient Light: 3-2000 lux (adjustable)
- Time Delay: Min. 10sec±3sec, Max. 12min±1min
- Rated Load: Max. 800W (incandescent lamp), 300W (energy saving lamp)
- Detection Range: 360°
- Detection Distance: 1-8m (radius), adjustable
- HF System: 5.8GHz CW radar, ISM band
- Transmission Power: <0.2mW
- Installation Height: 2-6m
- Power Consumption: Approx. 0.9W
- Detection Moving Speed: 0.6-1.5m/s
